28
Fuel Supply System Features
• Horizontal Fuel Conditioning Module (HFCM)
• (1) Chassis Mounted 10 Micron Fuel Filter
• (1) Engine Mounted 4 Micron Fuel Filter
• Water Separator
• Fuel Cooler
48
Fuel supply s y s t e m
49
Fuel Supply System Features
• The fuel supply system uses a new Horizontal Fuel
Conditioning Module (HFCM). The HFCM filters fuel,
separates water, senses water, and recirculates warm
fuel through the pump during cool fuel conditions.
• The 6.4L Power Stroke
®
Diesel also uses 2 fuel
filters and a stand alone fuel cooler system.
