Speedometer: Indicates the
current vehicle speed.
Engine coolant temperature
gauge: Indicates engine coolant
temperature. At normal operating
temperature, the needle will be in
the normal range (between “H” and
“C”). If it enters the red section, the
engine is overheating. Stop the
vehicle as soon as safely possible,
switch off the engine and let the
engine cool.
Never remove the coolant reservoir cap while the engine is
running or hot.
Odometer: Registers the total miles (kilometers) of the vehicle.
• Standard instrument cluster
• Optional instrument cluster
Refer to Message Center in the
Drivers Controls chapter on how to
switch the display from Metric to
English.
Trip odometer: Registers the miles (kilometers) of individual journeys.
• Standard instrument cluster
Press and release the
SELECT/RESET button to toggle
between odometer and trip
odometer display.
TRIP
TRIP
2005 Explorer (exp)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
15
