Rotate
the
wrench
socket
out
from
the
handle.
Removing
the
spare
tire
Do
not
use
an
impact
wrench
on
the
winch
drive
nut.
This
will
damage
the
spare
tire
winch.
1.
Open
the
cover
from
the
carpeting
on
cargo
floor
to
expose
the
winch
drive
nut.
2.
Insert
the
lug
wrench
on
the
winch
drive
nut.
The
wrench
will
stop
moving
and
forward
resistance
to
turning
will
be
felt
when
properly
engaged.
2005
Explorer
(exp)
Owners
Guide
(post-2002-fmt)
USA
(fus)
Tires,
Wheels
and
Loading
168
167
169
