Ford F650 2006 User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Fuse Description
304 — Air ABS relay
Hydraulic modulator relay
401 — Not used
501 — Not used
502 — Not used
503 — Not used
* Mini fuse **Maxi fuse
Air brake trailer tow relays (if equipped)
Fuse/Relay
Location
Fuse Amp
Rating
Description
1 30A* Trailer tow ABS feed
2 30A* Trailer tow park/marker lamps
3 30A* Trailer tow stop lamps
4 30A* Trailer tow turn/stop lamps (combined)
Trailer tow turn lamps (separate)
5 — Not used
R1 — Trailer tow ABS relay
2006 F-650/750 (f67)
Supplement
USA (fus)
Roadside Emergencies
150
