Adjusting
the
front
power
seat
(if
equipped)
The
control
is
located
on
the
outboard
side
of
the
seat
cushion.
Press
to
raise
or
lower
the
front
portion
of
the
seat
cushion.
Press
to
raise
or
lower
the
rear
portion
of
the
seat
cushion.
Press
the
control
to
move
the
seat
forward,
backward,
up
or
down.
2006
F-650/750
(f67)
Supplement
USA
(fus)
Seating
and
Safety
Restraints
71
70
72
