Rear Interior Lamp (If Equipped)

E169470

You can switch dome lamps on by pressing

the button.

AMBIENT LIGHTING (If Equipped)

Adjust the ambient lighting using the

touchscreen.

Fusion Energi / Fusion Hybrid (CC7) Hybrid Electric Vehicle (HEV)/Plug-In Hybrid Electric Vehicle (PHEV), Canada/United States of America, enUSA, Edition date: 201602, Second Printing

Lighting

Default Chapter4
