Lighting Control
qHeadlights
To turn on the lights, turn the headlight
switch on the end of the control lever.
Switch Position
Headlights Off Off On
Tail lights
Parking lights
Number plate lights
Instrument panel
illumination
Off On On
NOTE
To prevent discharging the battery, don't
leave the lights on while the engine is
off unless safety requires them.
qLights-On Reminder
If lights are on and the key is removed
from the ignition switch, a continuous
beep sound will be heard when any door
is opened.
qHeadlight Main-Low Beam
Push the lever forward for mai n beam.
Pull back to original position for low
beam.
Main beam
Low beam
qFlashing the Headlights
To flash the headlights, pull the lever fully
toward you. The headlight switch does
not need to be on, and the lever will return
to the normal position when released.
Driving Your Ford
Switches and Controls
5-39
