TECHNICAL SPECIFICATIONS
For Models: GLDB957JB* ADW750EA*
GLDB958JB* ADW850EA*
GPDB998JC*
WATER SUPPLY
Suggested Min. Water
Temperature
120° F
Pressure (PSI)
Minimum/Maximum
20/120
Connection (NPT) 3/8"
Water Valve Flow Rate
(GPM)
0.83
Water Fill Time
(± 3 Seconds)
87
Water Volume Per Fill
(Gal.)
1.2
Water Level in Tub
Just to bottom of
element supports
Total Gallons
(normal wash)
6.0
Water Recirculation Rate
(GPM)
12
ELECTRICAL
Rating 120V 60Hz
Separate Circuit 15 Amp
Total Amps (Load
Rated)
11.0
Recirculate Motor RPM
Amps
Thermal Cutout Temp.
3200 ccw
3.4
150° C
PTC Heating Element
During Wash Cycle
During Dry Cycle
900 Watts
700 Watts
High Limit Thermostat
opens at
200° F
Temp Assure
All cycles except
China/Crystal
136° F
Water Temp
Temp Assure
China/Crystal Cycle
127° F
Water Temp
Hi-Temp Wash
143° F
Water Temp
Hi-Temp Rinse
145° F
Water Temp
* = Color Code
DIAGRAM INDEX
MODEL
NUMBER
CYCLE
CHART
WIRING
DIAGRAM
GLDB957JB* B - 1 B - 1
GLDB958JB* B - 1 B - 1
GPDB998JC* B - 1 B - 1
ADW750EA* B - 2 B - 2
ADW850EA* B - 2 B - 2
COMPONENT RESISTANCE - OHMS
Timer Motor 2357
PTC Heating Element 9.28
Pump Motor Windings 4.3
Drain Motor Windings 28
Vent Door Actuator 1893
Dispenser Actuator 1928
Water Valve Solenoid 699
Blower Motor 214
