FS N8560 Series User Manual

Step 1: Connect a computer to the console port of the switch using the console cable.
Step 2: Start the terminal simulation software such as HyperTerminal on the computer.
Step 3: Set the parameters of the HyperTerminal: 9600 bits per second, 8 data bits, no parity, 1 stop
bit and no ow control. (PS: The Baud rate of N8560-32C is 115200)
Step 4: After setting the parameters, click Connect to enter.
Troubleshooting
Conguration the Switch
The indicator on the front panel of the host is OFF. The Status indicator of the fan module is OFF, and
the fan does not work. The indicator of the power module is OFF.
Please check the following:
First disconnect the power cord of the power module.
1. Whether the cables of the cabinet have been correctly connected.
2. Whether the cabinet power sockets are loosely connected to power modules.
3. Whether the power modules are installed correctly.
Power System Fault
Conguring the Switch Using the Console Port
x
Quick Connect
Protocol:
The port may be manually entered or selected from the list.
Serial
Flow Control
DTR/DSR
RTS/CTS
XON/XOFF
Save sessionShow quick connect on startup
Open in a tab
Connect
Cancel
COM3
9600
8
None
1
Port:
Baud rate:
Data bits:
Parity:
Stop bits:
Name of pipe:
