En-2
NAME OF PARTS
4 Operating Control Panel
5 SWING Indicator Lamp (orange)
6 TIMER Indicator Lamp (green)
7 OPERATION Indicator Lamp (red)
8 Remote Control Signal Receiver
9 MANUAL AUTO button
1 Air Filter
2 Air Flow Direction Flaps
3 Air Intake Grille
Electrical Breaker
This breaker is installed during the
electrical installation.
AUXB07/09/12/14/18L
AU
A20/25/30/36/45/54L
12
3
SWING TIMER OPERATION
4
567
8
9
SWING TIMER OPERATION
MANUAL
AUTO
4
567 9
8
12
3
Control unit (optional)
Wireless Remote Controller Wired Remote Controller Simple Remote Controller
For operation method, please refer to the Operating Manual of each device.
9369313028_OM_en.p65 29/8/06, 15:462
