En-5
CLEANING AND CARE
● Before cleaning the unit, be sure to stop the unit and disconnect the power supply.
● Do not stand on an unstable platform when cleaning.
● When removing and replacing the air filters, be sure not to touch the heat exchanger, as per-
sonal injury may result.
● Be sure the intake grille is installed securely.
● When cleaning the unit’s body, do not use water hotter than 40 °C, harsh abrasive cleansers, or
volatile agents like benzene or thinner.
● Do not remove any part from the unit except for the filter.
● If dirt is allowed to accumulate on the Air Filter, air flow will be reduced, lowering operating
efficiency and increasing noise.
● AUXB07/09/12/14/18L
During periods of normal use, the air filters should be cleaned every two weeks.
● AU A20/25/30/36/45/54L
During periods of normal use, the air filters should be cleaned every two months.
CAUTION!
Cleaning the air filter
● AUXB07/09/12/14/18L
1. Remove the air filter.
1 Push the intake grille’s hooks inward towards the center of the unit to open the intake grille.
2 Pull out the filter from the intake grille.
2. Cleaning
Cleaning the Air filter
Remove dust with a vacuum cleaner or by washing. After washing, be sure to allow it to dry thoroughly in a shady place
befor reinstalling.
3. Re-attach the air filter to the intake grille.
1 Replace the air filter into its holder.
2 Make sure that the air filter makes contact with the filter stopper when it is replaced into its holder.
3 Close the intake grille and push the intake grille’s hooks outward.
Grille Hook
11
Air Filter
2
33
Grille Hook Filter Holder Intake Grille
Filter Stopper
Air Filter
1
2
9369313028_OM_en.p65 11/9/06, 13:205
