Fujitsu Airstage AUXB07L User Manual

En-6
Cleaning the body
Wash the body with warm water, and then dry with a clean and soft cloth.
When not using for an extended period
Leave the breaker on for at least 12 hours before starting operation when it is to be used again.
● AU A20/25/30/36/45/54L
1. Remove the air filter.
1 Push the intake grille pushbuttons (two places).
2 Open the intake grille.
3 Hold down the hook at A and pull the filter out.
2. Cleaning
Cleaning the Air filter
Remove dust with a vacuum cleaner or by washing. After washing, be sure to allow it to dry thoroughly in a shady place
before reinstalling.
3. Re-attach the air filter to the intake grille.
1 When reinstalling the filter, be sure that the hooks at A and B engage correctly into place.
2 Close the intake grille.
B
A
A
B
Filter
Intake grille
3
OPEN
2
PUSH
1
9369313028_OM_en.p65 29/8/06, 15:466

Fujitsu Airstage AUXB07L Specifications

General

Brand	Fujitsu
Model	Airstage AUXB07L
Category	Air Conditioner
Language	English
