1. Specifications
Type Inverter heat pump
Model name AOYG36KBTB AOYG45KBTB AOYG54KBTB
Power supply 230 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Indoor unit combination
AUXG18KVLA × 2
ARXG18KLLAP × 2
AUXG22KVLA
× 2
ARXG22KMLA × 2
AUXG24KVLA × 2
ARXG24KMLA × 2
AUXG18KVLA × 3
ARXG18KLLAP × 3
Capacity
Cooling
Rated
kW 9.5 12.1 13.4
Btu/h 32,400 41,300 45,700
Min.—Max.
kW 2.8—11.2 4.0—13.0 4.5—14.5
Btu/h 9,500—38,200 13,700—44,300 15,300—49,400
Heating
Rated
kW 10.8 13.5 15.5
Btu/h 36,800 46,000 52,900
Min.—Max.
kW 2.7—12.7 4.2—15.2 4.7—16.5
Btu/h 9,200—43,300 14,300—51,800 16,000—56,300
Input power
Cooling
Rated
kW
2.97 4.22 4.42
Max. 5.11 6.48
Heating
Rated 2.88 3.84 4.16
Max. 5.10 6.48
Current
Cooling
Rated
A
13.1 18.6 19.4
Max. 22.6 28.5
Heating
Rated 12.8 16.9 18.3
Max. 22.6 28.5
EER Cooling
kW/kW
3.20 2.87 3.03
COP Heating 3.75 3.52 3.73
Power factor
Cooling
%
98.3 98.8 98.9
Heating 98.2 98.9 98.8
Starting current A 13.1 18.6 19.4
Maximum operating current*
1
A 22.6 28.5
Fan
Airflow rate
Cooling
m
3
/h
3,750 4,450
Heating 3,750 4,450
Type × Q'ty Propeller × 1
Motor output W 100 120
Sound pressure level*
2
Cooling
dB (A)
55 57
Heating 55 57 59
Sound power level
Cooling
dB (A)
70 71 73
Heating 70 71 73
Heat exchanger type
Dimensions
(H × W × D)
mm
Main1: 756 × 905 × 18.2
Main2: 756 × 905 × 18.2
Main1: 966 × 905 × 18.2
Main2: 966 × 905 × 18.2
Sub: 966 × 543 × 18.2
Fin pitch 1.45
Rows × Stages 1 × 36 1 × 46
Pipe type Copper
Fin
Type (Material) Aluminum
Surface treatment Blue fin
Compressor
Type × Q'ty DC Twin rotary × 1
Motor output W 1,500 2,180
Refrigerant
Type (Global warming potential) R32 (675)
Factory charge g 1,900 2,700
Refrigerant oil
Type FW68D RmM68AF
Amount
cm
3
600 800
Enclosure
Material Steel sheet
Color
Beige
Approximate color of Munsell 10YR 7.5/1.0
Dimensions
(H × W × D)
Net
mm
788 × 940 × 320 998 × 940 × 320
Gross 966 × 1,027 × 445 1,176 × 1,027 × 445
Weight
Net
kg
52 67
Gross 60 75
Connection pipe
Size
Liquid
mm (in)
Ø9.52 (3/8)
Gas Ø15.88 (5/8)
Method Flare
Pre-charge length Total
m
30
Max. length (Total) 50
Max. length
(From the 1st sepa-
ration tube)
To the farthest in-
door unit
20
To the farthest in-
door unit—To the
nearest indoor unit
8
Max. height difference between outdoor
unit and each indoor units
30
Max. height difference between indoor
units
0.5
Operation range
Cooling
°C
-15 to 46
Heating -15 to 24
Drain hose
Material LDPE
Size mm Ø13.0 (I. D.), Ø16.0 to Ø16.8 (O. D.)
NOTES:
• Specifications are based on the following conditions:
–
Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum operating current is the total current of the indoor unit and the outdoor unit.
• *2: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
- 56 -
1. Specifications
OUTDOOR UNIT AOYG36-54KBTB OUTDOOR UNIT AOYG36-54KBTB
