Fujitsu ARXG24KHTAP User Manual

6. Capacity table
6-1. Model: AOYG36KBTB
TC: Total Capacity, SHC: Sensible Heat Capacity, IP: Input Power
¢
Cooling capacity (Twin)

Compact cassette type
Model: AUXG18KVLA × 2
AFR
m
3
/h
1360
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 6.91 5.09 1.03 7.15 5.10 1.06 7.31 5.11 1.08 7.72 5.36 1.09 8.13 5.60 1.11 8.58 5.78 1.13 9.27 6.05 1.15
-10 6.76 4.95 1.26 7.00 4.97 1.29 7.16 4.98 1.31 7.56 5.21 1.33 7.96 5.45 1.35 8.40 5.63 1.37 9.07 5.89 1.40
0 6.47 4.67 1.70 6.70 4.69 1.74 6.86 4.70 1.77 7.24 4.92 1.80 7.62 5.15 1.83 8.05 5.31 1.85 8.69 5.56 1.89
5 6.42 4.69 1.75 6.64 4.71 1.79 6.80 4.72 1.82 7.17 4.94 1.85 7.55 5.17 1.88 7.98 5.33 1.91 8.61 5.58 1.95
10 6.36 4.71 1.80 6.59 4.72 1.85 6.74 4.73 1.87 7.11 4.96 1.91 7.49 5.18 1.94 7.91 5.35 1.97 8.54 5.60 2.01
15 6.26 4.63 1.86 6.48 4.65 1.90 6.62 4.66 1.93 6.99 4.88 1.96 7.36 5.10 1.99 7.77 5.26 2.02 8.39 5.51 2.07
20 9.44 6.66 2.51 9.77 6.68 2.57 9.99 6.69 2.61 10.55 7.01 2.65 11.10 7.33 2.70 11.73 7.57 2.73 12.66 7.92 2.79
25 8.98 6.37 2.59 9.30 6.39 2.65 9.51 6.40 2.70 10.04 6.71 2.74 10.57 7.01 2.79 11.16 7.24 2.83 12.05 7.58 2.89
30 8.53 6.08 2.68 8.83 6.10 2.74 9.03 6.11 2.78 9.53 6.40 2.83 10.03 6.69 2.88 10.60 6.91 2.92 11.44 7.23 2.98
35 8.07 5.79 2.76 8.36 5.81 2.83 8.55 5.82 2.87 9.02 6.10 2.92 9.50 6.38 2.97 10.03 6.58 3.01 10.83 6.89 3.08
40 7.55 5.50 2.89 7.82 5.52 2.96 8.00 5.53 3.00 8.44 5.79 3.05 8.89 6.06 3.10 9.39 6.25 3.15 10.14 6.54 3.22
46 6.93 5.15 3.04 7.18 5.17 3.11 7.34 5.18 3.16 7.75 5.43 3.21 8.16 5.67 3.26 8.61 5.86 3.31 9.30 6.13 3.38

Sl
im duct type
Model: ARXG18KLLAP × 2
AFR
m
3
/h
1,880
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 6.91 5.09 1.03 7.15 5.10 1.06 7.31 5.11 1.08 7.72 5.36 1.09 8.13 5.60 1.11 8.58 5.78 1.13 9.27 6.05 1.15
-10 6.76 4.95 1.26 7.00 4.97 1.29 7.16 4.98 1.31 7.56 5.21 1.33 7.96 5.45 1.35 8.40 5.63 1.37 9.07 5.89 1.40
0 6.47 4.67 1.70 6.70 4.69 1.74 6.86 4.70 1.77 7.24 4.92 1.80 7.62 5.15 1.83 8.05 5.31 1.85 8.69 5.56 1.89
5 6.42 4.69 1.75 6.64 4.71 1.79 6.80 4.72 1.82 7.17 4.94 1.85 7.55 5.17 1.88 7.98 5.33 1.91 8.61 5.58 1.95
10 6.36 4.71 1.80 6.59 4.72 1.85 6.74 4.73 1.87 7.11 4.96 1.91 7.49 5.18 1.94 7.91 5.35 1.97 8.54 5.60 2.01
15 6.26 4.63 1.86 6.48 4.65 1.90 6.62 4.66 1.93 6.99 4.88 1.96 7.36 5.10 1.99 7.77 5.26 2.02 8.39 5.51 2.07
20 9.44 6.66 2.51 9.77 6.68 2.57 9.99 6.69 2.61 10.55 7.01 2.65 11.10 7.33 2.70 11.73 7.57 2.73 12.66 7.92 2.79
25 8.98 6.37 2.59 9.30 6.39 2.65 9.51 6.40 2.70 10.04 6.71 2.74 10.57 7.01 2.79 11.16 7.24 2.83 12.05 7.58 2.89
30 8.53 6.08 2.68 8.83 6.10 2.74 9.03 6.11 2.78 9.53 6.40 2.83 10.03 6.69 2.88 10.60 6.91 2.92 11.44 7.23 2.98
35 8.07 5.79 2.76 8.36 5.81 2.83 8.55 5.82 2.87 9.02 6.10 2.92 9.50 6.38 2.97 10.03 6.58 3.01 10.83 6.89 3.08
40 7.55 5.50 2.89 7.82 5.52 2.96 8.00 5.53 3.00 8.44 5.79 3.05 8.89 6.06 3.10 9.39 6.25 3.15 10.14 6.54 3.22
46 6.93 5.15 3.04 7.18 5.17 3.11 7.34 5.18 3.16 7.75 5.43 3.21 8.16 5.67 3.26 8.61 5.86 3.31 9.30 6.13 3.38
- 65 -
6-1. Model: AOYG36KBTB 6. Capacity table
OUTDOOR UNIT AOYG36-54KBTB OUTDOOR UNIT AOYG36-54KBTB

Fujitsu ARXG24KHTAP Specifications
