6. OUTDOOR FAN CONTROL
Cooling Dry Heating
ASYA14/18LCC 860/820/670/500
400/340/280
ASYB09/12LDC
280/250/230
( Table 8 : Outdoor fan speed )
*
The outdoor fan speed mentioned avobe depends on the compressor frequency.
(When the compressor frequency increases, the outdoor fan speed also changes to the higher
speed. When the compressor frequescy decreases, the outdoor fan speed also changes to the
lower speed.)
*
It runs at 500(A-D ZONE)/200(E,F ZONE) rpm for 20 seconds after starting up the outdoor fan.
*
After the defrost control is operated on the heating mode, the fan speed keeps at the higher speed
as table 9 without relating to the compressor frequency.
05-07
A-D
E
F
A-D
E
F
ZONE
800/760/470
400/280
09LDC: 200
12LDC: 250/200
09LDC: 200
12LDC: 250/200
500
400/280
200
500
400/280
820/750/670/550/450
760/680/470
Refer to Fig1.
(rpm)
*
Outdoor temperature falls, and if it becomes E and F zone(
Refer to Fig1), rotations of fan speed
will fall.
( Table 9 : Outdoor fan speed after the defrost )
ASYB09LDC
ASYB12LDC
ASYA14/18LCC
Min
800rpm
900rpm
950rpm
(1). Outdoor Fan Motor
AC Motor DC Motor
ASYA07/09/12LCC
ASYB09/12LDC
ASYA14/18LCC
(2). Fan Speed
Cooling Dry Heating
ASYA07/09LCC 830rpm 830rpm 830rpm
ASYA12LCC 820rpm 820rpm 820rpm
Following table shows the type of the outdoor fan motor. The control method is different
between AC motor and DC motor.
( Table 6 : Type of Motor )
( Table7:ACMotor )
In conjunction with the compressor ON/OFF, the fan speed operates at around the speed
shown above.
*
