Fujitsu ASYG12LMCE-R User Manual

En-5
7. ELECTRICAL WIRING
7.1. Wiring system diagram
WARNING
•Everywiremustbeconnectedrmly.
•Nowireshouldbeallowedtotouchrefrigeranttubing,thecompressororanymov-
ingpart.
•Loosewiringmaycausetheterminaltooverheatorresultinunitmalfunction.Are
hazardmayalsoexist.Therefore,besureallwiringistightlyconnected.
•Connectwirestothematchingnumbersofterminals.
Groundingline
Type60245IEC57
(Inter-unit)
OUTDOORUNIT
Pleaseconnectitto
thespeciedterminal.
INDOORUNIT
TERMINAL
Powerline
Controlline
7.2. Indoor unit wiring
1.Removethewirecover.(Remove1screw.)
2.Removethecableclamp.
3.Ringterminalsconnecttotheconnectioncable.
4.Connecttheringterminalsfullyintotheterminalblock.
5.Fastentheconnectioncablewithacableclamp.
Wirecover
Wirecover
Screw
Screw
Screw
Screw
Insertthewirecovertabintothesquarehole
oftheindoorunitandfastenwithascrew.
Connectioncable
60mm
40mm
Cableclamp
Cableclamp
Earth(Ground)wire
7.3. How to connect wiring to the terminals
Cautionwhenwiringcable
Whenstrippingofftheinsulationofaleadwire,alwaysuseaspecialtoolsuchasawire
stripper.Ifthereisnospecialtoolavailable,carefullystriptheinsulationwithaknifeetc.
(1) Usering terminalswith insulatingsleevesasshowninthegureto connect to the
terminalblock.
(2) Securelyclamptheringterminalstothewiresbyusinganappropriatetoolsothatthe
wiresdonotcomeloose.
Strip:10mm
Ringterminal
Sleeve
(3) Usethespeciedwires,connectthemsecurely,andfastenthemsothatthereisno
stressplacedontheterminals.
(4) Useanappropriatescrewdrivertotightentheterminalscrews.Donotuseascrew-
driverthatistoosmall,otherwise,thescrewheadsmaybedamagedandpreventthe
screwsfrombeingproperlytightened.
(5) Donottightentheterminalscrewstoomuch,otherwise,thescrewsmaybreak.
Screwwithspecialwasher
Wire
Ringterminal
Terminalblocks
Wire
Screwwithspecialwasher
Ringterminal
(6) Seethefollowingtablefortheterminalscrewtighteningtorques.
Tighteningtorque[N·m(kgf·cm)]
M4screw 1.2to1.8(12to18)
CAUTION
•Matchtheterminalblocknumbersandconnectioncablecolorswiththoseofthe
outdoorunit.
Erroneouswiringmaycauseburningoftheelectricparts.
•Connecttheconnectioncablesrmlytotheterminalblock.Imperfectinstallationmay
causeare.
•Alwaysfastentheoutsidecoveringoftheconnectioncablewiththecableclamp.(If
theinsulatorischafed,electricdischargemayoccur.)
•Alwaysconnectthegroundwire.
•Donotusetheearthscrewoftheindoorunitfortheconnectionotherthanaspecied
outdoorunit.
8. FINISHING
(1) Insulatebetweenpipes.
• Insulatesuctionanddischargepipesseparately.
• Forrear,right,andbottompiping,overlaptheconnectionpipeheatinsulationand
indoorunitpipeheatinsulationandbindthemwithvinyltapesothatthereisnogap.
• Forleftandleftrearpiping,butttheconnectionpipeheatinsulationandindoorunit
pipeheatinsulationtogetherandbindthemwithandvinyltapesothatthereisnogap.
• Forleftandleftrearpiping,wraptheareawhichaccommodatestherearpiping
housingsectionwithclothtape.
• Forleftandleftrearpiping,bindtheconnectioncabletothetopofthepipewith
vinyltape.
• Forleftandleftrearpiping,bundlethepipinganddrainhosetogetherbywrapping
themwithclothtapeovertherangewithinwhichtheytintotherearpiping
housingsection.
(2) Temporarilyfastentheconnectioncablealongtheconnectionpipewithvinyltape.
(Wraptoabout1/3thewidthofthetapefromthebottomofthepipesothatwater
doesnotenter.)
(3) Fastentheconnectionpipetotheoutsidewallwithasaddle,etc.
(4) Fillthegapbetweentheoutsidewallpipeholeandthepipewithsealersothatrain
waterandwindcannotblowin.
(5) Fastenthedrainhosetotheoutsidewall,etc.
*Locallypurchased
Pipe
Saddle*
Outsidewallcap*
Sealerputty*
(Outdoors)
Wall
Overlaptheinsulation
Vinyltape*
Wrapwithclothtape
Clothtape(accessory)
Drainhose*
Connectioncable
Pipe
Drainhose
Checkthefollowing:
GOOD
Drainhose
Saddle
Liftedup Wave Endinwater
Drainhose Connectionpipe
Wallpipe Connectioncable
Left piping For connection from the left rear
Pipe
Connectionpipe
(heatinsulation)
Indoorunitpipe
(heatinsulation)
PROHIBITED
Bindthepipestogether
sothatthereisnogap.
SealAisusedwhenthediameter
ofgaspipeisØ12.70ormore.
Buttconnectionpipe(heat
insulation)againsttheindoor
unitpipe(heatinsulation)and
wrapwithsealAsothatthere
isnogap.
9333005225_IM_2L.indb 5 10/12/2017 08:48:45
