Fujitsu AUXG07KVLA Service Manual

4-2. Vertical louver control
¢ Wall mounted type (For KGTE and 18–24KMTB)
Each time the button is pressed, the air direction range will change as below:
3
4
5
2
1
1 2 3 4 5
Front view
Remote controller display is not changed.
4-3. Adjust the horizontal louver
¢ Wall mounted type (For KGTB, KMTE, 07–14KMTB, KMCC,
KMCE, KETA, and KETE)
Move the horizontal louvers to adjust airflow direction you prefer.
Horizontal louver
Knob
4-2. Vertical louver control - (04-57) - 4. Louver control
CONTROL AND FUNCTIONS CONTROL AND FUNCTIONS
