4-5. All louver control (For Compact cassette type)
• All louver operation
When the mode is selected, the standard louver position of the each mode is set.
Operation mode Standard Position
Cooling 1
Dry 1
Heating 4
Monitor 1
NOTES:
• Setting of the wireless remote controller is not displayed on the wired remote controller.
• The setting louver of the individual control function cannot be controlled.
4-6. Swing operation
¢ Compact cassette type
• To select vertical airflow swing operation
When the swing signal is received, the vertical airflow direction louver starts to swing.
– Swinging range
• Cooling mode/dry mode/fan mode: 1 ↔ 4
• Heating mode: 1 ↔ 4
– When the indoor fan is S-LOW or stop mode, the swing operation is interrupted and it stops at
either upper end or bottom end.
¢ Wall mounted type
• To select vertical airflow swing operation
When the swing signal is received, the vertical airflow direction louver starts to swing.
– Swinging range
• Cooling mode/dry mode/fan mode (1 to 3): 1 ↔ 4
• Heating mode/fan mode (4 to 6): 3 ↔ 6
– When the indoor fan is S-LOW or stop mode, the swing operation is interrupted and it stops at
either upper end or bottom end.
¢ Floor type
• To select vertical airflow swing operation
When the swing signal is received, the vertical airflow direction louver starts to swing.
– Swinging range
• Cooling mode/dry mode/fan mode: 1 ↔ 5
• Heating mode: 1 ↔ 5
– When the indoor fan is S-LOW or stop mode, the swing operation is interrupted and it stops at
either upper end or bottom end.
4-5. All louver control (For Compact cassette type)
- (04-64) - 4. Louver control
CONTROL AND FUNCTIONS CONTROL AND FUNCTIONS
