Fujitsu B23T-7 User Manual

Getting started
Adjusting height
The height adjustment is fixed in the transport position.
1
2
► To free the fixing, remove the locking
pinontheflange (1).

The height of the monitor can be adjusted
by approximately 130 mm.
► Grasp the monitor with both hands on
the right and left edge of the casing
and move it up or down (2).
Adjusting the i
nclination
The inclination of th e monitor can be adjusted by -3° (forwards) and +35°
(backwards) from its vertical position.
► Hold the monitor with both hands on the left and right sides of the casing
and move it to the desired angle.
Adjusting the rotation
The monitor can b e rotated by ±170°.
► Grasp the monitor with bo th hands on the right and left edge of the casing
and turn it to the desired position.
Fujitsu 15

Fujitsu B23T-7 Specifications

General

Brand	Fujitsu
Model	B23T-7
Category	Monitor
Language	English
