Operation
Changing the mon itor settings with the butto ns
of the control panel
Depending on the m odel, the control panel will either have buttons or touch
sensors. In the following s ections, only buttons will be mentioned. However,
the text also applies to models with touch sensors.
The buttons on the control panel have m ultiple functions. When the OSD
menu is active, the current meaning of the buttons is shown directly
over the buttons on the edge of the screen.
The display (softke y icon) over the bu ttons varies depending on the sub-menu chosen.
Key Function
Call up OSD m enu
Activate/deactivate ECO operating mode
Select input signal (digital/analog)
Adjust volume
Adjust brightness
Perform auto-adjustment of the monitor with analog input
Monitor: switching on/ off
Softkey icon
Function
Selecting the next menu item (sub-menu)
Selecting the previous menu item (sub-menu)
Opening the selected sub-menu
Going to the next s etting
Going to the previous setting
Decreasing the set value
Increasing the set value
Accepting the applied settings and returning to main menu
Cancelling the applied settings and returning to main menu
Exiting OSD menu
Loudspeaker: switching off/on
When the OSD menu is not activated, you can apply the following settings directly:
22 Fujitsu
