Fujitsu PRIMERGY RX2510 M2 User Manual

RX2510 M2 Operating Manual 57
Starting up and operation
Indicator on hot-plug power supply unit
Figure 10: Indicator on hot-plug power supply unit
6.1.3 Indicators of the hot-plug system fans
A fan status indicator (LED on the system board) is assigned to each system
fan. The status indicators are not visible unless the housing is open. The
respective LED is set with commands in Server Management.
Pos. Indicator Status Description
1 Status indicator
green
flashing
power supply unit operational (standby
mode)
green on
power supply unit operational (server
operating)
orange on power supply unit failure
LED Meaning
lights orange Possible fan failure (rotation speed less than 70% of the
original speed) or fan failure
0
