2-2. Outdoor unit
¢
Model: ROG09KMCDN
Unit: mm
580
109
330
353
Pitch of bolts
for installation
Pitch of bolts for installation
Top view
4-
M1
0 hole
Side viewSide view
Front view
799 68 29016
33 30
19
542
20
Airflow
Bottom view Side view (Valve part)
37
399
Drain port Ø42
184
120
180
2-2. Outdoor unit - (01-6) - 2. Dimensions
