5.3 Self Test
25
NMEA Test result
OK: All input is good.
--: All input is no good.
01: NMEA1 (input from J1352#3 and #4) is no good or jumper wires are not
connected.
02: NMEA2 (input from J1352#1 and #2) is no good.
03: The scanner communication with scanner unit is no good.
12: NMEA1 and NMEA 2 are no good.
13: NMEA1 and the communication with the scanner unit are no good.
23: NMEA2 and the communication with the scanner unit are no good.
Panel test: The pressed key is shown by black. To finish the test, press [MENU] three times.
The buzzer sounds at the end of the test.
GPS test: When the black box GPS (GP-310B etc.) is connected, the program number and the
status of the GPS are shown. “OK” appears when the status is good and no
indication when no good.
