SP - 1
SPECIFICATIONS OF COLOR VIDEO SOUNDER
FCV-667
1. GENERAL
(1) Display 6-inch diagonal CRT
(2) Echo Color 8 colors (including background color) according to echo intensity.
Monochrome display is also available. The background color is selectable
from blue, light blue, white and black.
(3) Basic Range Meters: 5/10/20/40/80/150/200/300
Feet: 15/30/60/120/200/400/600/1000
Fathoms: 3/5/10/20/40/80/100/150
Passi/Braza: 3/5/10/30/50/100/150/200
The basic ranges can be changed on the system menu.
(4) Range Shift Up to 300 meters (1000 feet, 150 fathoms, 200 passi/braza)
(5) Zoom Range Times 2, 3, 4 and 5 ranges
(6) Bottom Lock Expansion Range
5/10 meters, 10/20 feet, 2/5 fathoms, 2/5 passi/braza
(7) Auto Mode Automatic adjustment of range and gain
(8) Display Mode High Frequency (HF), Low Frequency (LF), Dual (high and low
frequency 1/2 display on each), Zoom (high/low freq. And Zoom),
NAV (Graphical and numerical displays of water depth, water
temperature, ship’s speed, L/L data, etc), and A-scope Display
(9) Zoom Display Marker Zoom, Bottom Zoom and Bottom-lock Expansion
(10) Display Advance Speed Lines/TX: Freeze, 1/8, 1/4, 1/2, 1/1, 2/1
(11) TX Frequency/ Output power
50 and 200 kHz (alternately transmitted), 300 W
(12) Pulse-length/TX rate
Display End Depth (m) 5 10 20 40 80 150 300
Pulse-Length (ms) 0.2 0.2 0.2 0.4 0.8 1.5 3.0
TX Rate (pulse/min) 600 600 600 375 187 100 50
(13) Interference Rejecter Rejects unwanted signals by comparing last and present echoes in
strength.
(14) Alarm Fish and Bottom alarms, Temperature alarm*
(15) Input/output data NMEA 0183 or CIF format
Input RMB, BWC, RMC, RMA, GLL, VTG, VHW, MTW, XTE
Output SDDBT, YCMTW*, VWVHW*, SDDPT
CIF Input L/L, Ship’s speed, Course, Waypoint ID, Range/bearing to Waypoint,
Water temperature, Cross-track Error
