Furuno FE-700 Service Manual

1
SYSTEM CONFIGURATION
The FE-700 consists of Display Unit ( FE701 ) , Distribution Box ( FE702 ), Transducer
Switching Box ( EX-8 ) and Matching Box ( MB-502/MB-504 ). The Switching Box and
Matching Box connected to switching box are supplied optionally.
TRANSDUCER
DISTRIBUTION
BOX
FE-702
DISPLAY UNIT
FE-701
JUNCTION BOX
JIS F8821-1
MATCHING BOX MB-502 (for 50B-6B)
MB-504 (for 200B-8B)
JB JB
IEC 61162-1
EIA-232C
IEC 61162-1
Navigation Device
Navigation Device
Personal Computer
IEC 61162-1
JB
TRANSDUCER SWITCH BOX
EX-8
DIGITAL DEPTH INDICATOR
FE-720
CONTACT CLOSURE
BUZZER
: Standard Supply
Ship’s mains
100-115 VAC/200-230 VAC
or
24 VDC
: Optional Supply
