1-2
1.2 Boards & Major Components
DISPLAY UNIT
Board Name FR-2115 FR-2125
SPU Board 03P9253
PTU (PWR) Board DC : 03P9246, AC : 03P9245
FILTER Board DC : 03P9226, AC : LF-210
TX-HV Board HV-9017A HV-9017B
PANEL Board (in control head) 03P9255
PAL Board (in control head) 03P9254
PAR Board (in control head) 03P9256
INT Board 03P9252
Mother Board 03P9251
ARP Board (Optional ARP-26) 18P9002 B
RP Board (Optional RP-26) 14P0298
Card I/F Board (Optional RP-26) 14P0299
PDM Board PDM-9025
Gyro Board (Optional GC-8) 64P1106 A
PM Board (Optional PM-30/50) 03P9225
CRT Unit CDT2136B
SCANNER UNIT
Board Name FR-2115 FR-2125
MODULATOR Board 03P9244 A 03P9244 B
RFC Board 03P9243 A 03P9243 B
IF AMP Board 03P9232
INTERFACE Board 03P9242
Limitter RU-9099
MIC RU-9253/RU-9371
Magnetron MG5241 MG5436
Circulator RC-3686
Scanner Motor D8G-516 (24 rpm)/D8G-571 (42 rpm)
Signal Cable RW-4873
