Furuno FR-2125 Service Manual

4-3
4.2 Jumper Settings
Board Specification Jumper Settings Remarks
03P9245A
(PTU Board, AC)
100 VAC, 24 rpm
JP1: Yes
JP2: Yes
JP3: Yes
JP4: No
JP91: No
JP92: No
R98:4.7 k ohms
03P9245C
(PTU Board, AC)
100 VAC, 42 rpm
JP1: Yes
JP2: Yes
JP3: Yes
JP4: No
JP91: No
JP92: Yes
R98: 1.2 k ohms
03P9245D
(PTU Board, AC)
220 VAC, 24 rpm
JP1: No
JP2: No
JP3: No
JP4: Yes
JP91: No
JP92: No
R98:4.7 k ohms
03P9245F
(PTU Board, AC)
220 VAC, 42 rpm
JP1: No
JP2: No
JP3: No
JP4: Yes
JP91: No
JP92: Yes
R98: 1.2 k ohms
03P9246A
(PTU Board, DC)
24 VDC, 24 rpm
JP91: No
JP92: No
R98: 4.7 k ohms
03P9246C
(PTU Board, DC)
24 VDC, 42 rpm
JP91: No
JP92: Yes
R98: 1.2 k ohms
HV-9017A 10 kW (FR-2115)
JP1: 300 V
JP2: 330 V
HV-9017B 25 kW (FR-2125)
JP1: 500 V
JP2: 330 V
INS RX (C) fromat J468: J1-J2
INS RX (H) fromat J469: J1-J2
J1-J2: Current loop
J3-J4: RS-422
03P9252
(INT Board)
ANALOG input level
J471: J1-J2
J1-J2:L, J3-J4:M, J5-J6:H
Battery connection
JP1: Yes
03P9253
(RP Board)
not used JP2: No
