Before cleaning, checking or repairing the
appliance, make sure that the motor has been
switched off and has cooled down. Remove
the spark plug connector to prevent accidental
starting.
MAINTENANCE AFTER EACH USE
1. air filter
Loosen the knob and remove the air filter
cover. Remove the filter element and brush off
any sawdust. If the filter is clogged, take it
apart in half and wash it out in petrol. When
using compressed air, blow through from the
inside. Remove the socket up to a
audible click to reassemble the filter halves.
2. oil supply opening
Remove the guide rail and check the oil supply
opening for blockage.
(1) Oil supply opening
3. guide rail
When the guide rail is dismounted, remove
the accumulated sawdust from the guide
groove and the oil supply opening. Lubricate
the front gear through the lubrication hole at
the front of the LM rail.
(1) Oil supply opening
(2) Lubrication opening
(3) gear wheel
