Original Bedienungsanleitung FUXTEC FX-MS125_de_en_fr_ita_es_rev01
49
27. Component overview
2) Air filter cover
3) Choke lever
4) Tank
5) Starter grip
6) 3-tooth blade
7) Scythe head
8) Protecting cover
9) Drive shaft
10) Eyelet for shoulder strap
11) Throttle lever
12) On/Off switch
13) Throttle cable
14) Two-handed handle
15) Locking lever for throttle
16) Throttle release
lever
