Gardena R40Li Operator‘s User Manual

26 - English
3. INSTALLATION
3.5 Connecting the boundary wire
Connect the boundary wire to the charging station:
1. Place the cable ends in the connector:
• Open the connector.
• Place the wire in the connector grip.
2. Press the connector together using a pair of
pliers. Press until you hear a click.
3. Cut off any surplus boundary wire. Cut 1 - 2 cm
above respective connectors.
4. Press the connector onto the contact pin, marked
A, on the charging station.
Carefully check that the connector is properly
fitted.
IMPORTANT INFORMATION
The boundary wire must not be crossed when
connecting to the charging station. The right
hand wire end must be connected to the right
hand pin on the charging station and the left
hand wire end to the left pin.
IMPORTANT INFORMATION
The right hand connector must be connected
to the right hand metal pin on the charging
station and the left hand wire end to the left
connector.
