Garmin AIS 800 User Manual

Connection Considerations
Device Ports
Item Description
USB port
1
NMEA 2000
®
Power and NMEA
®
0183
AIS antenna (required, not included)
VHF radio (optional)
External GPS antenna (optional)
2
1
Used with the included USB cable when connecting to a computer to program the device
2
An external GPS antenna is required when the device is installed in a location where it cannot receive GPS signals, especially in metal-hulled vessels.
4

Garmin AIS 800 Specifications

General

Transmit Power	2 W
Frequency	156.025 MHz to 162.025 MHz
Water Rating	IPX7
Connectivity	NMEA 2000, NMEA 0183
DSC Capable	Yes
Operating Temperature	-15°C to 55°C
Storage Temperature	-20°C to 70°C
Power Consumption	Less than 6 W
GPS	Integrated GPS receiver
Antenna Connector	SO-239
Channels	AIS 1 (161.975 MHz), AIS 2 (162.025 MHz)
Weight	1.3 lbs (590 g)
AIS Class	Class B
