Garmin AIS 800 User Manual

Item Description
Compatible NMEA 2000 chartplotter or other device
Garmin AIS 800 device
Ignition or in-line switch
NMEA 2000 power cable
NMEA 2000 drop cable
Garmin AIS 800 device power connection (Connecting the Device to Power, page5)
12Vdc power source
NMEA 2000 terminator or backbone cable
NMEA 2000 T-connector
NMEA 2000 terminator or backbone cable
7

Garmin AIS 800 Specifications

General

Transmit Power	2 W
Frequency	156.025 MHz to 162.025 MHz
Water Rating	IPX7
Connectivity	NMEA 2000, NMEA 0183
DSC Capable	Yes
Operating Temperature	-15°C to 55°C
Storage Temperature	-20°C to 70°C
Power Consumption	Less than 6 W
GPS	Integrated GPS receiver
Antenna Connector	SO-239
Channels	AIS 1 (161.975 MHz), AIS 2 (162.025 MHz)
Weight	1.3 lbs (590 g)
AIS Class	Class B
