Garmin GMA 350 User Manual

190-01134-11 GMA 350/350c/350H/350Hc Installation Manual
Rev. J Page 4-6
4.5 Audio Inputs and Outputs
4.5.1 COM Audio Inputs and Outputs
4.5.2 NAV/TRFC Audio Inputs
4.5.3 Receiver Audio Inputs
Table 4-6. COM
Pin Name Connector Pin I/O
COM 1 AUDIO IN HI J3501 9 In
COM 1 AUDIO LO J3501 10 --
COM 2 AUDIO IN HI J3501 13 In
COM 2 AUDIO LO J3501 14 --
COM 3 AUDIO IN HI (011-02385-10, -30, -12, -50, and -52
Only
)
J3501 3 In
COM 3 AUDIO LO (011-02385-10, -30, -12, -50, and -52
Only
J3501 4 --
COM 1 MIC AUDIO OUT HI J3501 11 Out
COM 2 MIC AUDIO OUT HI J3501 15 Out
COM 3 MIC AUDIO OUT HI (011-02385-10, -30, -12, -50,
and -52 Only
)
J3501 5 Out
Table 4-7. NAV/TRFC
Pin Name Connector Pin I/O
NAV 1 AUDIO IN HI
J3501
17 In
NAV AUDIO IN HI (011-02385-12 and 011-02385-52 Only)
NAV 1 AUDIO LO
J3501
18 --
NAV AUDIO IN LO (011-02385-12 and 011-02385-52 Only)
NAV 2 AUDIO IN HI
J3501
19 In
TRFC AUDIO IN HI (011-02385-12 and 011-02385-52 Only)
NAV 2 AUDIO LO
J3501
20 --
TRFC AUDIO IN LO (011-02385-12 and 011-02385-52 Only)
Table 4-8. AUX
Pin Name Connector Pin I/O
AUX 1 AUDIO IN HI
J3501
21 In
AUX 1 AUDIO IN LO
J3501
22 --
AUX 2 AUDIO IN HI
J3501
7 In
