82
GPSmap 76CS
Appendices
PHYSICAL
Case: Rugged, fully gasketed, water resistant, IEC-529,
IPX7 (Submersible 1 meter @ 30 minutes)
Size: 6.2”H x 2.7”W x 1.4”D
Weight: 7.6 ounces (153 g) with batteries installed
Display: 1.5”W x 2.2”H, 256-color, high resolution,
transrefl ective TFT (160 x 240 pixels) Backlit
Antenna: Built-in quad helix, remote antenna capability
Compass: Accuracy; +/- 5 degrees
1
, resolution; 1 degree
Altimeter: Accuracy; +/- 10 feet
1
, resolution; 1 foot
Keypad: Nine multifunction backlit keys
Operating Range: 5 to 158
o
F (-15 to 70
o
C)
2
PERFORMANCE
Receiver: WAAS enabled, 12 parallel channel
Acquisition Time: Warm: Approximately 15 seconds
Cold: Approximately 45 seconds
AutoLocate
™
: Approximately 2 minutes
Update Rate: Once per second, continuous
GPS Accuracy
Position: < 15 meters (49 feet), 95% typical
3
Velocity: 0.05 meter/sec steady state
Specifi cations
GPSmap 76CS
GPSmap 76CS Owner's Guide copy.indd 82 3/30/2004, 2:00:50 PM
