190-01499-02 GTX 3x5 TSO Installation Manual
Rev. 1 Page 1-7
Table 1-4 Physical Characteristics - Remote Mount Units
The GTX 3x5 display is a sunlight readable LCD display.
Characteristic Specification
Horizontal mount
Height 1.68 inches (43 mm)
Width 6.3 inches (160 mm)
Length (unit, mount, and connector backshells) 9.92 inches (224 mm)
Vertical mount
Height 6.55 inches (166 mm)
Width 1.4 inches (35 mm)
Length (unit, mount, and connector backshells) 12.1 inches (308 mm)
GTX 335R weight (unit only) 1.71 lb (0.78 kg)
GTX 335R weight (horizontal mount - mounting tray, connector
backplate, and connectors)
2.53 lb (1.15 kg)
GTX 335R weight (vertical mount - mounting tray, connector
backplate, and connectors)
2.73 lb (1.24 kg)
GTX 335R with GPS weight (unit only) 1.82 lb (0.83 kg)
GTX 335R with GPS weight (horizontal mount - mounting tray,
connector backplate, and connectors)
2.64 lb (1.20 kg)
GTX 335R with GPS weight (vertical mount - mounting tray,
connector backplate, and connectors)
2.84 lb (1.29 kg)
GTX 345R weight (unit only) 1.97 lb (0.89 kg)
GTX 345R weight (horizontal mount - mounting tray, connector
backplate, and connectors)
2.79 lb (1.27 kg)
GTX 345R weight (vertical mount - mounting tray, connector
backplate, and connectors)
2.99 lb (1.37 kg)
GTX 345R with GPS (unit only) 2.08 lb (0.94 kg)
GTX 345R with GPS (horizontal mount - mounting tray, connector
backplate, and connectors)
2.08 lb (0.94 kg)
GTX 345R with GPS (vertical mount - mounting tray, connector
backplate, and connectors)
3.10 lb (1.41 kg)
Operating temperature range
-4°F to 131°F (-20°C to + 55°C)
For more details refer to the
environmental qualification form at
Garmin’s Dealer Resource Center
.
See section section 1.7.1 for form
part number.
Altitude range 55,000 feet
Humidity 95% non-condensing
Cooling External cooling not required
Audio output 100 mW into 500 Ω
