Garmin GTX 325 User Manual

190-01499-02 GTX 3x5 TSO Installation Manual
Rev. 1 Page 3-6
3.5.1 Transponder Antenna
TBD
3.6 Installation Configurations
3.7 Special Tools Required
Some connectors use crimp contacts. Use crimp tools listed in table 3-2 to ensure reliable crimp contact
connections for the rear D-sub connectors.
Table 3-2 Recommended Crimp Tools
NOTE
Insertion/extraction tools from ITT Cannon are all plastic; others are plastic with metal
tip.
Manufacturer Hand Crimping Tool
22-28 AWG (P3251, P3252)
Positioner
Insertion/Extraction
Tool
Military PN M22520/2-01 M22520/2-09
M81969/14-01
M81969/1-04
Positronic 9507-0-0-0 9502-4-0-0 M81969/1-04
ITT Cannon 995-0001-584 995-0001-739
000849490
274-7048-000MIL
AMP 601966-1 601966-6
91067-1
2031838-1
Daniels AFM8 K42
M81969/14-01
M81969/1-04
Astro 615717 615725
M81969/14-01
M81969/1-04
