Page 3-2 GTX 330/GTX 330D Installation Manual
Revision R 190-00207-02
NOTES
1. Non-Garmin part numbers shown are not maintained by Garmin and consequently are subject
to change without notice.
2. Extracting the 16 and 18 AWG contact requires that the expanded wire barrel be cut off from
the contact. It may also be necessary to push the pin out from the face of the connector when
using an extractor due to the absence of the wire. A new contact must be used when
reassembling the connector.
3. Contact Garmin for crimp instructions for use with 16 AWG contact.
3.3 Circuit Breaker Placard
Install a Circuit Breaker Placard labeled Transponder or Transponder 1, Transponder 2 as appropriate as
indicated in FAA Advisory Circular AC 43.13-2B, paragraph 114.
3.4 Post Installation Checkout
After the installation is complete, refer to Section 5 for system configuration.
Verify proper operation of the transponder by testing in accordance with Appendix F to 14 CFR Part 43 –
ATC Transponder Tests and Inspections.
