Navigation Function Codes
Setup Action Code # Range of settings or Responses Default
Navigation Gain 15 1 lowest gain, 73 highest gain 42
Navigation Trim Gain 16 1 lowest gain, 73 highest gain 49
Use Synthetic XTE 37 2 settings on, off off
Change Sign of XTE 18 2 settings on, off off
Use Magnetic North 39 2 settings on, off on
Set North 48 Hold Down Select Load Button, press and
release Deckmount Button to set north
See Notes code #48
Enable Checksums 347 2 settings on, off on
Notes:
Code 1.
Seastate adjustments toward least responsive slow the heading response down. Most of the time
you will want to run with this parameter all the way at the top of its range.
Codes 15 & 16.
The best way to tune GPS tracking is to start with the trim gain at its minimum and set the
coupling gain as high as it can be set without causing oscillations around the course line capture.
Code 18.
Changes the direction to steer to courseline. Some GPS’ steer the wrong way, turn this
parameter on to fix the GPS problem.
Code28.
The man overboard maneuver can be tuned to run over the target at any given speed, but may
miss by a distance at another speed. If you choose to use this function, tune it with these two
tuning codes. If the man passes on your starboard reduce code 28.
Fine Tuning Codes
Seastate Filtering 1 1 least responsive steering, 5most
responsive steering.
5
Rudder Gain 2 1 Lowest gain, 60 highest gain 22
Counter Rudder Gain 3 1 lowest gain, 60 highest gain 37
Speed Schedule 35 4 settings 1 aggressive, 2 moderate, 3 mild,
4 weak
4
31
Code 1 Sea State Filter.
If the Autopilot seems to be too active in rough water (the kicker motor is overactive) but works perfect in
calm water, adjusting the Sea State Filter may help. Factory default sets this code at the top of its range (4)
which is most active (least active is 1) . Most of the time you will want to run with this parameter at the the
top of its range. To decrease the autopilots sensitivity in rough water 1) Press and release [SETUP}on the
handheld, the setup LED will be lit. 2) Press the [IDLE/RES] button and light up the number 1 LED .
3) Press the down arrow button to decrease the autopilots sensitivity. Note: When the autopilot is shut
off, the autopilot will return to its factory default setting unless the setting is saved See page 28, Step 5.
31
Navigation Function Codes
Setup Action Code # Range of settings or Responses Default
Navigation Gain 15 1 lowest gain, 73 highest gain 42
Navigation Trim Gain 16 1 lowest gain, 73 highest gain 49
Use Synthetic XTE 37 2 settings on, off off
Change Sign of XTE 18 2 settings on, off off
Use Magnetic North 39 2 settings on, off on
Set North 48 Hold Down Select Load Button, press and
release Deckmount Button to set north
See Notes code #48
Enable Checksums 347 2 settings on, off on
Notes:
Code 1.
Seastate adjustments toward least responsive slow the heading response down. Most of the time
you will want to run with this parameter all the way at the top of its range.
Codes 15 & 16.
The best way to tune GPS tracking is to start with the trim gain at its minimum and set the
coupling gain as high as it can be set without causing oscillations around the course line capture.
Code 18.
Changes the direction to steer to courseline. Some GPS’ steer the wrong way, turn this
parameter on to fix the GPS problem.
Code28.
The man overboard maneuver can be tuned to run over the target at any given speed, but may
miss by a distance at another speed. If you choose to use this function, tune it with these two
tuning codes. If the man passes on your starboard reduce code 28.
Fine Tuning Codes
Seastate Filtering 1 1 least responsive steering, 5most
responsive steering.
5
Rudder Gain 2 1 Lowest gain, 60 highest gain 22
Counter Rudder Gain 3 1 lowest gain, 60 highest gain 37
Speed Schedule 35 4 settings 1 aggressive, 2 moderate, 3 mild,
4 weak
4
31
Navigation Function Codes
Setup Action Code # Range of settings or Responses Default
Navigation Gain 15 1 lowest gain, 73 highest gain 42
Navigation Trim Gain 16 1 lowest gain, 73 highest gain 49
Use Synthetic XTE 37 2 settings on, off off
Change Sign of XTE 18 2 settings on, off off
Use Magnetic North 39 2 settings on, off on
Set North 48 Hold Down Select Load Button, press and
release Deckmount Button to set north
See Notes code #48
Enable Checksums 347 2 settings on, off on
Notes:
Code 1.
Seastate adjustments toward least responsive slow the heading response down. Most of the time
you will want to run with this parameter all the way at the top of its range.
Codes 15 & 16.
The best way to tune GPS tracking is to start with the trim gain at its minimum and set the
coupling gain as high as it can be set without causing oscillations around the course line capture.
Code 18.
Changes the direction to steer to courseline. Some GPS’ steer the wrong way, turn this
parameter on to fix the GPS problem.
Code28.
The man overboard maneuver can be tuned to run over the target at any given speed, but may
miss by a distance at another speed. If you choose to use this function, tune it with these two
tuning codes. If the man passes on your starboard reduce code 28.
Fine Tuning Codes
Seastate Filtering 1 1 least responsive steering, 5most
responsive steering.
5
Rudder Gain 2 1 Lowest gain, 60 highest gain 22
Counter Rudder Gain 3 1 lowest gain, 60 highest gain 37
Speed Schedule 35 4 settings 1 aggressive, 2 moderate, 3 mild,
4 weak
4
