Garmin TR-1 Gold User Manual

TR-1 Gold Autopilot System Parts List
Electro-Hydraulic unit……………….…….
120-2100-00
Kinked tubing with tie wrap……………….
3 ea. Truss head machine screws #8-32x 3/4
3 ea. Lock washer nuts #8-32………………
3 ea. Truss head sheet metal screws #8 x 3/4
Sensor Ball Unit……………………………….……..
120-2200-00
Sensor Ball Bracket ………………………………….
3 ea. Pan head machine screws #8-32 x 1”…………
3 ea. Lock washer nuts #8-32…………………………
3 ea. Pan head sheet metal screws #8 x 1”…………
Sensor Ball Capture Cage...………………………….
Deck Mount Switch/Tach …………………………
120-2215-00
4
