OPM_SGS_ISG_10K_40K_0US_V010.doc 10/45 Installation Guide SG Series 10, 20, 30 & 40 kVA
2.2 LAYOUT SG Series 30 AND 40 KVA
SGT5000_030-040_UPS_GE_02
Fig. 2.2-1 SG Series general view
SGT5000_030-040_UPS_GE_03
Q1
Q2
ON
OFF
OFF
ON
Fig. 2.2-2 SG Series general view with open doors
SGT5000_030-040_UPS_GE_04
4
1
3
2XBXA CR
OFF
ON
OFF
ON
Fig. 2.2-3 SG Series general view with optional 5
th
harmonic filter
and removed protection panels
1 Opening for top cable entry
2 Opening for bottom cable entry
3 Terminals for Utility input and
load output
4 Terminals for external Battery
connection
CR Connectivity Rack
XA Terminals for 24VDC Auxiliary
Power Supply connection
XB Terminals for EPO connection
