67
/
Cop
y
r
i
g
ht
Gen
er
al
E
l
ect
r
i
c
2
01
1
9/23/2012
Fill System
Fill Hose
Fill Funnel
Fill Funnel Seal
Flood Switch:
•
located
in the S
ump
•
Series Cir
cuit with water valve,
when in flood
condition
it will
open the circuit to
the valve
Water Valv
e:
•
Located front left corner
under the
tub
•
13.5 VDC, 32 ohms.83 GPM
•
1 minute solenoid activation time
Clamp
66
68
Table of Contents
Installation
11
Lower Rack
22
Upper Rack
25
Demo Mode
29
Top Control
53
Main Control Board
56
Control Board Layout
59
Fill System
67
Flood Switch Removal
71
Circulation System
72
Wire Harness Routing
86
Clamp Removal
87
Drain System
92
Drain Water
94
Dry System
102
Door Latch
105
Turbidity Sensor
109
Cycle Information
111
