Circulation System
Wash Pump will cycle during operation to allow proper Diverter
position. It is normal for the motor to run, stop for 1 second,
Restart, stop and pause for 5 - 8 seconds, restart and repeat this
algorithm throughout the cycle. Motor run times will change
depending on cycle
Spray Arms alternate from Lower Arm to Mid and Upper Arms.
This allow the system to use less water
Diverter directs water to either the Lower Spray Arm or both
Mid and Upper Spray Arms. Some models have options to select
Wash zones (upper or lower)
