Electrical Connections
Drop-In Range
Loosenscrewsforthejunctionbox
coverandrotateoutofplaceorremove
thecover.
C2
Examinethejunctionboxlocationand
determinethebestroutingoftheconduit
andselectthebestavailable7/8"
diameterknockout.Avoidusingholesin
thetopofthejunctionboxtopreventthe
conduitfrominterferingwiththebackof
therange.
C3
Breakopentheselectedknockoutby
placingabladedscrewdriveronthe
scoredopeninginthejunctionboxand
strikethescrewdriverwithahammer.
(Pliersmayberequiredtocompletethe
removaloftheknockout.)
Removehousefuseoropencircuit
breaker.
C4
WARNING:Improperconnectionof
aluminumhousewiringtocopper
leadscanresultinanelectrical
hazardorfire.Useonlyconnectors
designedforjoiningcoppertoaluminum
andfollowthemanufacturer's
recommendedprocedureclosely.
Feedwiresandconduitthroughtheopen
holeandsnaptheconduitfittingintothe
hole.Routetheconduitinamannerthat
willnotinterferewiththerearwirecover.
Theconduitmustberoutedbelowthe
wirecover.
C6
GENERALNOTEFORALLWIRENUT
APPLICATIONS:THEPROPERSIZEWIRE
NUTSHALLBEPLACEDOVERTHE
STRIPPEDLEADSANDTHEWIRENUT
TWISTEDUNTILTHEWIRENUTCANNOT
BEPULLEDFROMTHELEADS.NO
CONDUCTORSHALLBEEXPOSEDINTHE
CONNECTION.THEEXCEPTIONTOTHE
CONDUCTORBEINGEXPOSEDISTHE
BARECOPPERGROUNDCONNECTION.
7/8" Knock-out
Cover Rotated
from box Opening
Positiontherangeinfrontofthe
openingbutslightlytothesideina
mannerthatapersoncanenterthe
openingtowiretherangetothehouse
wiringinthejunctionbox.
C5
C1
GEA01049
