GE LOGIQ F8 Service Manual

GE LOGIQ F SERIES
D
IRECTION 5446617-100, REVISION 10 BASIC SERVICE MANUAL
3 - 20 Section 3-6 - System Configuration
3-6-5-5 Digital Printer Instructions
Follow these steps to set up the paper size of the printer, take Sony UP-D897 as an example.
1.) Press Utility-->System-->Peripherals. Select the UP-D897 from the pull-down menu under
Standard Printer Properties. Click Properties.
2.) Select Properties from Printer pull-down menu.
3.) Click Printing Preferences at the bottom of Properties Window.
4.) Select Paper Size. Press Apply. Press OK.
5.) Press Save, then Exit.
Figure 3-19 Properties
Figure 3-20 Properties
Figure 3-21 Printing Preferences

GE LOGIQ F8 Specifications

General

Brand	GE
Model	LOGIQ F8
Category	Medical Equipment
Language	English
