3-10
MAC
1200 resting ECG anal
ysis system
Revision D
2012250-095
System T
est Function:
Recording Test
Recording Test
The recording test is act
ivated by pressing the
5
key.
A window with 2 channels is displayed.
The selected speed and sensitivity are displayed.
Terminate with any key.
Table 5. Motor Speed Test
Key
Test Performed
Speed
Selects the speed
Start/Stop
Starts and stops a real time 2 channel recording
53
55
