3-14 MAC 1200 resting ECG analysis system Revision D
2012250-095
System Test Function: Electrode Test
Electrode Test
The electrode test is started by pressing the 8 key.
The following menu is displayed.
The status of each electrode is displayed. Electrode OK or disconnected is displayed
as follows.
Status = 0 -> Electrode OK
Status = 1 -> Electrode disconnected
With the P key, the pace electrode can be selected. The selected pace electrode is
displayed.
The status cable indicates if a cable is connected to the patient ECG input or not.
Table 8. Electrode Test
Electrode Test
Terminate with any key
Select pace electrode (key P)
Pace electrode LA
Cable = 10 electrodes (or no cable)
To Next Page
