1.1 Introduction
The
GE (General Electric) Digital Energy Match UPS
, an uninterruptible power supply, protects your
equipment from all forms of power interference, including complete power failures.
1.2 Safety Rules
!
CAUTION: RISK OF ELECTRICAL SHOCK
. After installation, the UPS system (UPS +
battery pack) contains batteries. The appliance outlets may be electrically live, even when
the UPS is disconnected from the mains.
!
The UPS contains potentially hazardous voltages. Do not open the UPS, there are no user
serviceable parts inside.
!
All maintenance and service work, including replacement of the batteries, should be
performed by qualified service personnel.
1.3 Transport / Storage
!
No liability can be accepted for any transport damage when the equipment is shipped in non-
original packaging.
!
Store the UPS in a dry location with the batteries in a fully charged state. Storage temperature
must be within -20 +45
"
C. If the unit is stored for a period exceeding 3 months, optimal battery
lifetime is obtained if the storage temperature does not exceed 25°C.
!
If the unit is stored for an extended period of time, the batteries must be recharged periodically.
Connect the battery pack to the UPS. Subsequently connect the unit to a wall outlet and recharge
the batteries for 24 hours:
- if the storage temperature is within -20 and +30°C: every 3 months,
- if the storage temperature is within -20 and +45°C: every month.
The shipment contains a Match UPS, a battery pack, one mains power cord, two IEC male-female output
cords, a data cable, a CD ROM and this manual. After unpacking, inspect the UPS for damage. If any
damage is present please immediately notify the carrier and place of purchase.
IMPORTANT
:
Before making any connection and switching on the UPS, please check the following conditions:
!
your mains supply is 220 - 240 Volts and 50 or 60 Hz, and
!
the total power demand of the connected equipment does not exceed the rated output power of
the UPS (indicated on the rating label) (7, fig. 1).
2.1 Installation Rules
!
The UPS is intended to be used in normal domestic and office situations.
!
Protect the UPS, according to the wiring rules, with a 16A D-type fuse.
!
The UPS must be powered from a single phase grounded wall outlet. Do not use extension
cords.
!
Avoid locations that are excessively humid, near water, near heat sources or in direct sunlight.
!
The ambient temperature should not exceed 40
"
C. Optimal battery lifetime is obtained if the
ambient temperature does not exceed 30
"
C.
!
If you stack the UPS and its battery pack, always place the UPS on top.
!
It is important that ventilation air can move freely around and through the unit. Do not block the air
vents.
!
Do not plug appliances such as electric heaters, toasters and vacuum cleaners into the UPS.
!
Be careful when connecting laser printers: be sure that the demanded power does not exceed the
capacity of the UPS.
!
The sum of the leakage currents of the UPS and the connected loads should not exceed 3.5mA.
