7. Specications
APV 1700-2M-TL APV 2300-2M-TL APV 3100-2M-TL APV 4400-2M-TL APV 5200-2M-TL
Input Data
Max. DC power 1700Wp 2300Wp 3150Wp 4400Wp 5200Wp
Max. DC voltage 450V 500V 500V 580V 580V
PV voltage range MPPT 120V - 450V 120V - 450V 120V - 450V 120V - 500V 120V - 500V
Max. number of parallel strings 1 2 2 3 3
Number of MPP trackers 1 1 1 1 1
MPPT input current 0-10A 0-12A 0-15A 0-20A 0-20A
Max DC input Isc current 15A 15A 20A 27A 27A
Output (AC)
Nominal AC output (Pac nom) 1600W 2000W 2850W 4200W 4600W
(1)
/ 5000W
Max. AC power 1650W 2200W 3000W 4400W 5000W
Max. output current 8A 11A 13A 21A 23A
Short circuit current,
(=1.5*In)
11A 13A 19A 28A 30A
Nominal AC voltage range 200V-250V 200V-250V 200V-250V 200V-250V 200V-250V
AC grid frequency range 50/60Hz,±5Hz 50/60Hz,±5Hz 50/60Hz,±5Hz 50/60Hz,±5Hz 50/60Hz,±5Hz
Power factor (cos phi) 1 1 1 1 1
Harmonic distortion (THD grid) <3% <3% <3% <3% <3%
AC connection Singie phase Single phase Singie phase Singie phase Single phase
Efficiency
Max. efficiency 97% 97% 97% 97.8% 97.8%
European efficiency (Euro ETA)
[5, 10, 20, 30, 50, 100% of
Pac nom]
96%
[90.11%; 93.25%;
96.5%; 96.81%;
95.97%; 95.5%]
96%
[90.12%; 93.28%;
96.51%; 96.82%;
96.01%; 95.5%]
96.5%
[93.85%; 95.35%;
96.51%; 96.83%;
96.5%; 96%]
97.4%
[93.88%; 96.36%;
97.51%; 97.85%;
97.98%; 97.40%]
97.4%
[93.91%; 96.40%;
97.54%; 97.89%;
98.01%; 97.40%]
Protection devices
Power switch, DC side yes
(2)
yes
(2)
yes
(2)
yes
(2)
yes
(2)
DC reverse polarity protection yes yes yes yes yes
AC short - circuit protection yes yes yes yes yes
Ground fault monitoring yes yes yes yes yes
Grid monitoring yes yes yes yes yes
Integrated all - pole sensitive
leakage current monitoring unit
yes yes yes yes yes
General data
Dimensions (W / D/ H) in mm 362/329/131.5 362/329/131.5 362/329/131.5 406/406/191.5 406/406/191.5
Weight 11.5 kg 11.7 kg 12.2 kg 21 kg 21 kg
Operating temperature range
-25°C … +60°C [-13°F ...+140°F],
with power derating above +50°C [+113°F]
(3)
Noise emission (typical) ≤25 dB (A) ≤25 dB (A) ≤25 dB (A) ≤25 dB (A) ≤25 dB (A)
Consumption: operating
(standby)/night
<5W/<0.5W <5W/<0.5W <5W/<0.5W <5W/<0.5W <5W/<0.5W
Topology transformerless transformerless transformerless transformerless transformerless
Cooling concept No fan No fan No fan No fan No fan
Installation: Indoors /
Outdoors
yes / yes yes / yes yes / yes yes / yes yes / yes
Protection class IP65 IP65 IP65 IP65 IP65
Warranty: 5 years yes yes yes yes yes
Certificates and approvals VDE0126, ENEL (DK5940), G83 (declaration), RD1663 (declaration)
(1) APV 5200-2M-TL-DE (Version for Germany). (2) DC power switch not present in models APV ....-2M-TL-UK. (3) Power derating 0.7 @ +60°C. [+140°F]
