1-1. Indoor unit connection patterns
¢ 4-unit multi-split type
AOHG30KBTA4
Combination no. Unit 1 Unit 2 Unit 3 Unit 4 Total
1 7 22 — — 29
2 7 24 — — 31
3 9 22 — — 31
4 9 24 — — 33
5 12 18 — — 30
6 12 22 — — 34
7 12 24 — — 36
8 18 18 — — 36
9 18 22 — — 40
10 18 24 — — 42
11 22 22 — — 44
12 22 24 — — 46
13 24 24 — — 48
14 7 7 12 — 26
15 7 7 14 — 28
16 7 7 18 — 32
17 7 7 22 — 36
18 7 7 24 — 38
19 7 9 9 — 25
20 7 9 12 — 28
21 7 9 14 — 30
22 7 9 18 — 34
23 7 9 22 — 38
24 7 9 24 — 40
25 7 12 12 — 31
26 7 12 14 — 33
27 7 12 18 — 37
28 7 12 22 — 41
29 7 12 24 — 43
30 7 14 14 — 35
31 7 14 18 — 39
32 7 14 22 — 43
33 7 14 24 — 45
34 7 18 18 — 43
35 7 18 22 — 47
36 7 18 24 — 49
37 9 9 9 — 27
38 9 9 12 — 30
39 9 9 14 — 32
40 9 9 18 — 36
41 9 9 22 — 40
42 9 9 24 — 42
43 9 12 12 — 33
44 9 12 14 — 35
45 9 12 18 — 39
46 9 12 22 — 43
47 9 12 24 — 45
48 9 14 14 — 37
49 9 14 18 — 41
50 9 14 22 — 45
- 3 -
