2. Dimensions
2-1. Model: AOHG30KBTA4
Side view (Valve part)
600
353 330
109
4- M1 0 hole
820
19
99
884
20
20
18
16
315
410
37
Drain port Ø42
Side viewSide view Front view
Top view
Pitch of bolts for installation
Bottom view
Pitch of bolts for installation
Airflow
Unit: mm
17
71
168
46
92
92 ×3=276
- 300 -
2-1. Model: AOHG30KBTA4
2. Dimensions
OUTDOOR UNIT AOHG30KBTA4 OUTDOOR UNIT AOHG30KBTA4
